Wheel Dia. (mm) |
Tread Type |
Finish | Capacity (lbs) | Mounting Height (Inches) |
Swivel Radius (Inches) |
Part Number |
Fastening Selection |
---|---|---|---|---|---|---|---|
50 | Nylon or Urethane |
Bright Chrome | 75 | 2-1/2 | 1-3/4 | PPA50___BC | 507, 525, 605,634 637,639,828 |
50 | Nylon or Urethane |
Brass Plate | 75 | 2-1/2 | 1-3/4 | PPA50___BR | 507, 525, 605,634 637,639,828 |
50 | Nylon or Urethane |
Flat Black | 75 | 2-1/2 | 1-3/4 | PPA50___FB | 507, 525, 605,634 637,639,828 |
50 | Nylon or Urethane |
Satin Chrome | 75 | 2-1/2 | 1-3/4 | PPA50___SC | 507, 525, 605,634 637,639,828 |
50 | Nylon or Urethane |
Windsor Antique | 75 | 2-1/2 | 1-3/4 | PPA50___WA | 507, 525, 605,634 637,639,828 |
60 | Nylon or Urethane |
Bright Chrome | 100 | 2-7/8 | 2-3/16 | PPA60___BC | 525, 526, 545, 605 637,639 |
60 | Nylon or Urethane |
Brass Plate | 100 | 2-7/8 | 2-3/16 | PPA60___BR | 525, 526, 545, 605 637,639 |
60 | Nylon or Urethane |
Flat Black | 100 | 2-7/8 | 2-3/16 | PPA60___FB | 525, 526, 545, 605 637,639 |
60 | Nylon or Urethane |
Satin Chrome | 100 | 2-7/8 | 2-3/16 | PPA60___SC | 525, 526, 545, 605 637,639 |
60 | Nylon or Urethane |
Windsor Antique | 100 | 2-7/8 | 2-3/16 | PPA60___WA | 525, 526, 545, 605 637,639 |
Fastener Code | Length (Inches) |
Diameter (Inches) |
Thread Pitch (UNC) |
---|---|---|---|
828 | 5/8 | 1/4 | 20 |
507 | 1 | 5/16 | 18 |
525 | 1/2 | 5/16 | 18 |
526 | 1-1/4 | 5/16 | 18 |
545 | 7/8 | 5/16 | 18 |
605 | 1-1/2 | 3/8 | 16 |
634 | 1 | 3/8 | 16 |
637 | 3/4 | 3/8 | 16 |
639 | 5/8 | 3/8 | 24 |
Wheel Dia. (mm) |
Tread Type |
Finish | Capacity (lbs) | Mounting Height (Inches) |
Swivel Radius (Inches) |
Part Number |
Fastening Selection |
---|---|---|---|---|---|---|---|
50 | Nylon or Urethane |
Bright Chrome | 75 | 2-3/8 | 1-3/4 | PPA50___BC | 211,222,223,302 |
50 | Nylon or Urethane |
Brass Plate | 75 | 2-3/8 | 1-3/4 | PPA50___BR | 211,222,223,302 |
50 | Nylon or Urethane |
Flat Black | 75 | 2-3/8 | 1-3/4 | PPA50___FB | 211,222,223,302 |
50 | Nylon or Urethane |
Satin Chrome | 75 | 2-3/8 | 1-3/4 | PPA50___SC | 211,222,223,302 |
50 | Nylon or Urethane |
Windsor Antique | 75 | 2-3/8 | 1-3/4 | PPA50___WA | 211,222,223,302 |
60 | Nylon or Urethane |
Bright Chrome | 100 | 2-3/4 | 2-3/16 | PPA60___BC | 211,222,223,302 |
60 | Nylon or Urethane |
Brass Plate | 100 | 2-3/4 | 2-3/16 | PPA60___BR | 211,222,223,302 |
60 | Nylon or Urethane |
Flat Black | 100 | 2-3/4 | 2-3/16 | PPA60___FB | 211,222,223,302 |
60 | Nylon or Urethane |
Satin Chrome | 100 | 2-3/4 | 2-3/16 | PPA60___SC | 211,222,223,302 |
60 | Nylon or Urethane |
Windsor Antique | 100 | 2-3/4 | 2-3/16 | PPA60___WA | 211,222,223,302 |
Fastener Code | Length (Inches) |
Diameter (Inches) |
---|---|---|
302 | 1-1/2 | 5/16 |
Fastener Code | Length (Inches) |
Diameter (Inches) |
---|---|---|
222 | 1 | 3/8 |
211 | 1-7/16 | 7/16 |
223 | 7/8 | 7/16 |
Wheel Dia. (mm) |
Tread Type |
Finish | Capacity (lbs) | Mounting Height (Inches) |
Swivel Radius (Inches) |
Part Number |
Fastening Selection |
---|---|---|---|---|---|---|---|
50 | Nylon or Urethane |
Bright Chrome | 75 | 2-11/16 | 1-3/4 | PPA50___BC | 101,113 |
50 | Nylon or Urethane |
Brass Plate | 75 | 2-11/16 | 1-3/4 | PPA50___BR | 101,113 |
50 | Nylon or Urethane |
Flat Black | 75 | 2-11/16 | 1-3/4 | PPA50___FB | 101,113 |
50 | Nylon or Urethane |
Satin Chrome | 75 | 2-11/16 | 1-3/4 | PPA50___SC | 101,113 |
50 | Nylon or Urethane |
Windsor Antique | 75 | 2-11/16 | 1-3/4 | PPA50___WA | 101,113 |
60 | Nylon or Urethane |
Bright Chrome | 100 | 3-1/16 | 2-3/16 | PPA60___BC | 101,113 |
60 | Nylon or Urethane |
Brass Plate | 100 | 3-1/16 | 2-3/16 | PPA60___BR | 101,113 |
60 | Nylon or Urethane |
Flat Black | 100 | 3-1/16 | 2-3/16 | PPA60___FB | 101,113 |
60 | Nylon or Urethane |
Satin Chrome | 100 | 3-1/16 | 2-3/16 | PPA60___SC | 101,113 |
60 | Nylon or Urethane |
Windsor Antique | 100 | 3-1/16 | 2-3/16 | PPA60___WA | 101,113 |
Fastener Code | Top Plate (Inches) |
Bolt Hole Spacing (Inches) |
Bolt Hole Size (Inches) |
---|---|---|---|
101 | 1-1/2 x 1-1/2 | 1 x 1 | 3/16 |
113 | 1-3/16 x 2 | 13/16 x 1-9/16 | 3/16 |
